Concealed Overhead Door Closer Fire Rated For Glass Door Size 2-4 Adjustable
Concealed Overhead Closer,"invisible"door closer
EC103 Type meet UL standard,with CCCF certified
Precise Aluminum Body with Needle Bearing
Adjustable Closing &Latching Speed
Closer body 32mm Thickness.Non Handed Installation
Slide Tracking arm with hold-open function
The data on this represents our judgment of which are most similar , since no product is exactly alike each other,it is not guaranteed nor represented that any specific product exactly equals any other product.
Introduction
UL Listed Aluminum alloy Commercial Or Residential Automatic Hydraulic Door Closer
Advanced function of ECH door closer:
● Build-in hold function: stop at 75°
● Dual valves, closing and latching speed controlled by two separate regulating valves.
● Two speed valves: Closing speed valve 180°-15°, Latching speed valve 15°-0°
● Back check function: provide a temporary resistance between 70° to Maximum opening angle in door opening cycle to help prevent damage to door and or wall in case of the door opens with excessive force
● Delay Action: an added adjustment to delay the door closing from Maximum opening down to approximated 65°, convenience for the handicapped and elderly
● Barrier Free: meet ADA regulation engineered with reduced spring power to provide easier opening for handicapped and elderly
Power Adjustable Valve Clockwise: increase Power Counterclockwise: decrease Power
Concealed Overhead Door Closer Fire Rated For Glass Door Size 2-4 Adjustable
Aluminium Alloy Door Closer is a popular door closer it is durable and easy to use. As a professional door closer manufacturer in China, we provide customers various quality Fire Rated Door Closer and they apply to different commercial of doors. The Metal Door Closer is one kind of our Aluminium Alloy Door Closer. The material of UL Door Closer is cast aluminum ally, so it can keep the original shape very well. The Aluminium Alloy UL Door Closer can also keep smooth for a long time, not easy to broken, these two characteristics greatly reduce the possibility of Fire Rated UL Door Closer become old and bad. The Fire Rated Metal Door Closer can also keep long-term lubrication, make you convenient to open and close the door.The Fire Rated Door Hardware is smooth and easy to install and use, it can bring you high security and beauty. For Further information, please contact us.
Concealed Overhead Door Closer Fire Rated For Glass Door Size 2-4 Adjustable
Product name | UL Listed concealed door closer |
Product Model | EC103 |
Certification | GVEV.R41359 - Swinging Fire Door Closers _ UL Product iQ |
Material | Aluminum Alloy |
Door Width | 950mm |
Door Weight | 40-65kg |
Speed Control | Two way speed adjustable |
Finish | Silver or to order |
Suitable for | Wooden door, Metal door, Fire rated door, Escape door, Exit Door, etc. |
Concealed Overhead Closer,"invisible"door closer
EC103 Type meet UL standard,with CCCF certified
Precise Aluminum Body with Needle Bearing
Adjustable Closing &Latching Speed
Closer body 32mm Thickness.Non Handed Installation
Slide Tracking arm with hold-open function
Concealed Overhead Door Closer Fire Rated For Glass Door Size 2-4 Adjustable
MOQ | 100 sets |
Package | One piece white box or color box or blister card in standard export carton 10 sets/ Carton 19kg/Carton Carton size:51x29.5x18.5cm |
Sample time | 5-7working days |
Production lead time | About 45 days |
Shipping Port | Jiangmen, Guangdong, China |
